APPENDIX
A228/A248/A228I/A248I User’s manual
29
USB 1,2,3,4 Port
Audio Connector
Pin #
Signal Description
J53
Microphone (stereo) Pink
J54
Line Out (stereo) Green
Pin #
Signal Description
1
+5V
2
Data-
3
Data+
4
GND
