Athena S Series - Typical Configurations

Series S Solid-State Staging Controller Instruction Manual
2
Series S Solid-State Staging Controller Instruction Manual
3
1.2 Typical Configurations
Circular - SC Type Controller
Ordering code example:
10 Heating Steps
Code: SCA - 10
Any number SC Heat Stages up to ten. End board
follows last used stage.
SC End Board
(Always follows
last used stage)
SC Heat Stages
Step Delay Board
Input Conditioner
BLACK
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
YELLOW
GREEN
9
8
7
6
5
10
4
3
2
1
9
8
7
6
5
10
4
3
2
1
(Timing)
