1.3 Specifications
Input ‘A’: 4-20 mA dc. 60 mA max,
or 6 V dc, 9 V max. 135
ohms slidewire, 100-1000
ohms acceptable
Input ‘B’: Thermistor probe to match
range
Output: One amp per step max
(ten amps inrush)
Signal Isolation: 1500 volts from power
circuits and ground
Time Delay: Adjustable, from 2.5 to 12
seconds; automatic
slowdown near balance
Adjustments: Time Proportioning –
Adjustable from differential
to time proportioning
Span – Adjusts to input
range
Indication: L.E.D. logic status light on
each output stage.
Supply voltage: 120 V + 10%, - 15%,
50/60 Hz 4 VA plus total
contactor VA
Ambient Temperature: 30º to 130º F. (-1.1º to 54.4º C)
Dimensions: 13" L, 6" W, and 3" H
(34.3 cm L x 15.2 cm W x
8.9 cm H)
