Revision A
15
When [L6] is displayed in the parameter menu, press the <ENTER> function key to display the
hour value.
L7 – Load Factory Defaults
Options: (- - - - -) NOT enabled, indicating factory default loading has NOT been
selected
(LOAd) Enabled, indicating factory default loading has been selected
Default: (- - - - -) Not enabled
[L7] is used to restore the factory default settings to all the user programmable parameters.
When [L7] is displayed in the parameter menu, press the <ENTER> function key. Press the <Δ>
(Up) and <∇> (Down) function keys to move between [- - - - -] and [LOAd].
Press <ENTER> to set the selection and return to the parameter select menu. [L7] will be
displayed.
L8 – Software Revision
Options: N/A
Default: N/A
[L8] displays the current revision that is being used by the 2H main firmware.
L9 – Bargraph Display
Options: OFF - Disabled
ON - Enabled
Default: ON - Enabled
[L9] is used to enable or disable the analog bargraph display beneath the numeric portion of the %
Leakage display.
When [L9] is displayed in the parameter menu, press the <ENTER> function key to access the
stored setting.
Press the <Δ> (Up) and <∇> (Down) function keys to move the displayed setting between 0 and 1
on the display.
