7. Electrical connection
Do not over-tighten the terminal block lug, to avoid damaging or breaking the screw.
It is not recommended to use exible wires without round lugs.
Do not attach a rigid wire with a crimped round lug. The pressure on the lug can
cause malfunctions and abnormal heating of the cable.
Connect the cables securely to the terminal block. An incorrect installation poses
a risk of re.
Using lugs or end-ttings is prohibited.
25 mm
Rigid wire
Loop
Screw and
special washer
Terminal block
