Atlantic Vertigo 30 - Hydraulic Connection

(Supplied)
PTR Valve
(850kPa)
Untempered
hot water
(Kitchen,
laundry)
Tempered water
50°C
(Bathrooms)
Cold water
main supply
Non-return and
Isolang Valve
Line
Strainer
Drain lines
Pressure
Liming
Valve
(350-500 kPa)
4
2
7.
Hydraulic connection
