Compressor type I
max
(1) Max
fuse (1)
I
max
(2) Max fuse
(2)
GA 11 VSD+ IEC 50 Hz 230 V 42.5 A 60 A 45.6 A 60 A
GA 11 VSD+ IEC 50 Hz 400 V + N - - 26.0 A 32 A
GA 11 VSD+ IEC 50 Hz 400 V 24.4 A 25 A 26.0 A 32 A
GA 11 VSD+ IEC 50 Hz 500 V 19.5 A 25 A 20.8 A 25 A
GA 11 VSD+ IEC 60 Hz 200 V 48.8 A 60 A 51.9 A 60 A
GA 11 VSD+ IEC 60 Hz 230 V 42.5 A 60 A 45.6 A 60 A
GA 11 VSD+ IEC 60 Hz 380 V 25.8 A 25 A 27.3 A 32 A
GA 11 VSD+ IEC 60 Hz 460 V 21.3 A 25 A 22.8 A 32 A
GA 11 VSD+ UL/cUL 60 Hz 200 V 48.8 A 60 A 51.9 A 60 A
GA 11 VSD+ UL/cUL 60 Hz 230 V 42.5 A 60 A 45.6 A 60 A
GA 11 VSD+ UL/cUL 60 Hz 460 V 21.3 A 25 A 22.8 A 30 A
GA 11 VSD+ UL/cUL 60 Hz 575 V 17.0 A 25 A 18.3 A 25 A
Compressor type I
max
(1) Max
fuse (1)
I
max
(2) Max fuse
(2)
GA 15 VSD+ IEC 50 Hz 200 V 62.8 A 70 A 68.0 A 80 A
GA 15 VSD+ IEC 50 Hz 230 V 54.7 A 70 A 59.9 A 80 A
GA 15 VSD+ IEC 50 Hz 400 V + N - - 34.0 A 40 A
GA 15 VSD+ IEC 50 Hz 400 V 31.4 A 32 A 34.0 A 40 A
GA 15 VSD+ IEC 50 Hz 500 V 25.1 A 32 A 27.2 A 32 A
GA 15 VSD+ IEC 60 Hz 200 V 62.8 A 70 A 68.0 A 80 A
GA 15 VSD+ IEC 60 Hz 230 V 54.7 A 70 A 59.9 A 80 A
GA 15 VSD+ IEC 60 Hz 380 V 33.2 A 32 A 35.8 A 40 A
GA 15 VSD+ IEC 60 Hz 460 V 27.4 A 32 A 29.9 A 40 A
GA 15 VSD+ UL/cUL 60 Hz 200 V 62.8 A 70 A 68.0 A 80 A
GA 15 VSD+ UL/cUL 60 Hz 230 V 54.7 A 70 A 59.9 A 80 A
GA 15 VSD+ UL/cUL 60 Hz 460 V 27.4 A 35 A 29.9 A 40 A
GA 15 VSD+ UL/cUL 60 Hz 575 V 21.9 A 30 A 24.0 35 A
I
max
(1): maximum current in the supply lines at maximum load and nominal voltage for compressors
without integrated dryer.
Max fuse (1): maximum fuse size in case of compressors without integrated dryer.
I
max
(2): maximum current in the supply lines at maximum load and nominal voltage for compressors with
integrated dryer.
Max fuse (2): maximum fuse size in case of compressors with integrated dryer.
Setting of circuit breakers
Q1 1 A
Q15 0.5 A
Instruction book
120 2920 7109 23
