Atlas Copco GHS 900 VSD+ - Page 22

Instruction book
22 6996 0227 40
Name
Icon
Description
Service
Service required
Main screen display
Value lines display icon
Chart display icon
General icons
No communication / network problem
Not valid
Input icons
Icon
Description
Pressure
temperature
Digital input
Special protection
System icons
Icon
Description
Vacuum pump element
Fan
Frequency converter
Motor
Network problem
General alarm
