Atlas Copco GHS 900 VSD+

Instruction book
6996 0227 40 31
(i)
Set as main chart signal
3.7 Outputs menu
Control panel
Menu icon, outputs
Function
To call up Information regarding the actually measured data and the status of some outputs such as the
motor overload protection.
Procedure
Starting from the Main screen (see Main screen):
• Move the cursor to the action button Menu and press the enter key (2),following screen appears:
