bx = 1.5 mm² NSGAFOeU
l = 95 mm²
lx = 95 mm² EPR-CSP (BS6195-4C)
k = 70 mm²
j = 50 mm²
i = 35 mm²
54 = green/yel.
1 = brown
Wire size : Colour code :
a = 1 mm²
b = 1.5 mm²
c = 2.5 mm²
d = 4 mm²
e = 6 mm²
f = 10 mm²
g = 16 mm²
h = 25 mm²
0 = black
2 = red
3 = orange
4 = yellow
5 = green
6 = blue
7 = purple
8 = grey
9 = white
Legend
ABCDEF GHIJKLMN OP Q
X11
ON
P1 P0 P2
OFF
REMOTE
X11
S20 - Configuration
K103
K104 K102
K101
X11
CAN-H
GND
Input W/L-Input D+
Input Low Oil Pressure
Input High Coolant Telperature
Input Fuel Level (AST)
Input Emergency Stop
Input Remote Start
Input Space
Input Override Fuel shutdown
Common for Analogue inputs
CAN-L Engine CAN-bus Interface
0 Vdc (Batt-)
12/24 Vdc (Batt+)
Genarator Voltage L1
Genarator Voltage L2
Genarator Voltage L3
Genarator Voltage Neutral
Genarator Current Transfo L1
Genarator Current Transfo L2
Genarator Current Transfo L3
Genarator Current common COM
Fuel Control Relay Output
Start Relay Output Output
Light 1 Control Output
Light 2 Control Output
Light 3 Control Output
Light 4 Control Output
17
OUT-3
OUT-4
OUT-5
OUT-6
to Circ. Diagr POWER
Fuses F1-F2, Current Transfo.
a2
17
a2
12
a6
24
a3
23
a3
22
a3
21
a3
24
a3
23
a3
22
a3
21
a3
A1
1
18 19 20 5 10 11 12 13 14 15 16 17
2
Lc1003
21 22 23 24 29 30 31 32 3 4 6 7 8 9
125
a0
126
a0
141
c8
140
c8
17
a2
15
a3
5
a3
21
22
7
5
4321
S2
To Next Page
