- 84 -
A1 Generator control unit
B7 Fuel level sensor
E1 Preheat resistor
F10 Fuse 10A DC
G1 Battery 12Vdc
G2 Charging alternator
H6 Preheat light
K0 Starter solenoid
K1 Preheat relay
K2 Starter relay (pull)
K4 Fuel control relay
K5 Starter relay
K100 Remote start relay
K101-K104 Light control relay
K110 Mast down aux. relay (2)
K111 Mast up aux. relay (2)
KT10 Timer
M1 Starter motor
M6 Fuel feed pump
P7 Photocell (1)
S2 Emergency stop
S8 High coolant temperature switch
S9 Low oil pressure switch
S20 REMOTE/OFF/ON switch
S31 Brake on switch (2)
S32 Mast down switch (2)
S51 Mast down pushbutton
X10 Connector wire harness
X11 Auxiliary terminals
X25 Customer’s terminals
Y1 Fuel stop solenoid
Y10 Mast down solenoid
Z1 Buzzer (2)
(0.x) Optional mains connection
(see 1636 0024 44/00_03)
(1) Optional photocell
(2) Optional auto mast down system
(3) Optional override fuel shutdown
00_00_HiLight H4_EN.book Page 84 Monday, April 18, 2016 2:10 PM
