2920 1257 04
43
Instruction book
7.3.2 60 Hz
Compressor type LE15 LE22 LE40 LE55 LE75 LE110 LE150
Maximum working pressure for LE . . . . bar(e) 10 10 10 10 10 10 10
Maximum working pressure for
LE Trolley . . . . . . . . . . . . . . . . . . . . . . . bar(e) 9.5 9.5 9.5 9.5 9.5 9.5 9.5
Pre-set pressure difference for
LE Trolley . . . . . . . . . . . . . . . . . . . . . . . bar 1 1 1 1 1 1 1
Temperature at outlet valve, approx.
- Unsilenced compressor . . . . . . . . . . . . Celsius 49 54 80 74 59 67 127
- Silenced compressor . . . . . . . . . . . . . . Celsius 57 62 88 82 67 75 135
Power input at max. working pressure . . kW 2.36 3.38 6.36 7.57 9.97 12.83 17.87
Motor shaft speed . . . . . . . . . . . . . . . . . . r/min 1800 1800 1800 1800 1800 1800 1800
Free air delivery 2) . . . . . . . . . . . . . . . . . l/s 3.9 5.1 9.7 13.6 17.4 21.9 28.2
Oil capacity. . . . . . . . . . . . . . . . . . . . . . . l 0.8 0.8 0.8 1.4 1.7 1.7 1.7
Opening pressure of safety valve (not
for Block/Power Pack) . . . . . . . . . . . . . . bar(e) 11 11 11 11 11 11 11
Maximum sound pressure level 1):
- Standard version. . . . . . . . . . . . . . . . . . dB(A) 80 81 81 82 83 84 85
- Silenced receiver-mounted version . . . dB(A) 67 68 68 72 74 75 75
- Silenced pack version . . . . . . . . . . . . . dB(A) 65 66 66 70 70 72 73
7.4 Compressor data for LF 10 bar
7.4.1 50 Hz
Compressor type LF15 LF22 LF40 LF55 LF75
Maximum working pressure for LF . . . . . . . . . . . . . . bar(e) 10 10 10 10 10
Maximum working pressure for LF Trolley. . . . . . . . bar(e) 9.5 9.5 9.5 9.5 9.5
Pre-set pressure difference for LF Trolley . . . . . . . . . bar 1 1 1 1 1
Temperature at outlet valve, approx.
- Unsilenced compressor . . . . . . . . . . . . . . . . . . . . . . Celsius 40 44 45 50 51
- Silenced compressor . . . . . . . . . . . . . . . . . . . . . . . . Celsius 48 52 53 58 59
Power input at max. working pressure . . . . . . . . . . . . kW 2.05 2.71 5.11 5.89 8.65
Motor shaft speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . r/min 1500 1500 1500 1500 1500
Free air delivery 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . l/s 3.1 4.0 7.6 9.2 14.4
Opening pressure of safety valve (not for Block/
Power Pack) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . bar(e) 11 11 11 11 11
Maximum sound pressure level 1):
- Standard version. . . . . . . . . . . . . . . . . . . . . . . . . . . . dB(A) 82 83 83 84 86
- Silenced receiver-mounted version . . . . . . . . . . . . . dB(A) 69 70 70 74 77
- Silenced pack version . . . . . . . . . . . . . . . . . . . . . . . dB(A) 67 68 68 72 74
