Atlas Copco LH 11

15
LH 11, 18, 19 E, 22, 23 E, 27, 28 E, 39, 40 E
© 2008 Atlas Copco Construction Tools AB | No. 3392 5143 01 | 2008-02-29
Overhauling instructions
Cylinder
1. Mount the cylinder in a vice
2. Remove the locking ring
3. Remove the seal
4. Remove the locking ring
5. Remove the seal and the back-up washer
