Atlas Copco P6500T User Manual

- 30 -
EN
8 Technical specifications
8.1 Technical data for P3000(W)/P6500(T/W)/P8000(T/W) units
P3000 P3000W P6500 P6500T P6500W P8000 P8000T P8000W
AC output Frequency 50 Hz 60 Hz 50 Hz 50 Hz 60 Hz 50 Hz 50 Hz 60 Hz
Voltage 230 V 120/240 V 230 V 400/240 V 120/240 V 230 V 400/240 V 120/240 V
Power rating
2.3 kW /
2.3 kVA
2.5 kW /
2.5 kVA
5.0 kW /
5.0 kVA
5.0 kW /
6.25 kVA
5.0 kW /
5.0 kVA
6.0 kW /
6.0 kVA
6.0 kW /
7.5 kVA
6.5 kW /
6.5 kVA
Max. power
2.5 kW 2.8 kW 5.5 kW 5.5 kW 5.5 kW 6.5 kW 6.5 kW 7.0 kW
Engine Specification Single cylinder, forced air cooling, 4 strokes
Rpm 3000 3600 3000 3000 3600 3000 3000 3600
Fuel Gasoline
Engine oil capacity 0.6 l 1.1 l
Spark plug type
F7RTC (RN9YC)
Spark plug clearance 0.7 mm
Valve clearance (inlet/outlet)
0.10–0.15/0.15–0.20 mm
Ignition mode T.C.I.
Starting system Recoil Recoil / E-start
Displacement 196cc 389cc 420cc
Dimensions Net weight only for reference 46 kg 79 kg 81 kg 79 kg 83 kg 85 kg 83 kg
Overall dimensions (excluding
packing box) (L x W x H) 590 x 430 x 467 mm 681 x 546 x 550 mm
Capacity of fuel tank 15 l 25 l
Noise emission
(according to European
Directive 2000/14/EC
with amendment 2005/
88/EC
Measured Sound Pressure Level
at 4 m 75 dB(A) 75 dB(A) 81 dB(A)
Measured Sound Power Level
95 dB(A) 97 dB(A) 101 dB(A)
Guaranteed Sound Power Level
95 dB(A) 97 dB(A) 101 dB(A)
00_00_P-range_Combi 1.book Page 30 Wednesday, July 19, 2017 12:23 PM

Atlas Copco P6500T Specifications

General

Brand	Atlas Copco
Model	P6500T
Category	Portable Generator
Language	English
