Instruction manual
2954 2100 01 13
Warning Display (pop-up window)
In case when a Warning occurs, a pop-up window will
automatically be entered for as long as the warning is active, no
matter which view is active. The warning icons will be shown
(together with a continuous lit alarm LED at the fascia), which is
centered at the display. The Warning Display can always be left or
entered again by pushing the BACK button.
If more than one warning comes up, it's possible to scroll through
the warning messages with the UP and DOWN pushbuttons. The
newest warning will be placed at the bottom of the list (meaning
that the older warning stays at the display when a newer warning
comes up).
If one or more than one warning is present, an arrow at the right of
the display will be shown.
If a Shutdown comes up, the Shutdown Display is shown.
List of possible warnings:
LOW OIL PRESSURE
HIGH COOLANT
TEMPERATURE
CHARGING
ALTERNATOR
LOW FUEL LEVEL
LOW COOLANT
LEVEL
GENERATOR
OVERVOLTAGE
GENERATOR
UNDERVOLTAGE
85%
00000.8h
V
>
V
<
GENERATOR
OVERFREQUENCY
GENERATOR
UNDERFREQUENCY
SERVICE TIMER 1
SERVICE TIMER 2
ALARM
Hz
>
Hz
<
;
;
