Atlas Copco RE Qualifier II User Manual

Numbers 5 and 6 relate to how parameters are selected by an
external device. If number 5 is selected, only 4 parameters can be
accessed externally. The table below shows the relationship
between the parameters and how they are selected using the
inputs.
PRMD PRMC PRMB PARAM
0 0 0 A
0 0 1 B
0 1 0 C
1 0 0 D
If Binary Parameters (number 6) is selected, one of eight parame-
ters can be selected externally. The table below shows the rela-
tionship between the parameters and how they are selected using
the inputs.
PRMD PRMC PRMB PARAM
0 0 0 A
0 0 1 B
0 1 0 C
0 1 1 D
1 0 0 E
1 0 1 F
1 1 0 G
1 1 1 H
RE Qualifier System Manual 18
