60
Instruction Manual
Generator type DDG 110V
DDG IT 230V -
3 ph - 6kVA
DDG IT 230/400V -
3 ph - 6kVA
(XAS 47 DDG -
XAS 90 DD7G / DDG IT)
(XAS 47 DDG -
XAS 90 DD7G / DDG IT)
(XAS 47 DDG
-
XAS 90 DD7G
/ DDG IT)
Designation Unit Value Value Value
Alternator
1. Standard IEC 34-1 IEC 34-1 IEC 34-1
2. Make MECC ALTE MECC ALTE MECC ALTE
3. Model MR-1 -180/2 TR-1 -160/2 TR-1 -160/2
4. Rated output kVA 6 6 6
5. Degree of protection IP 23 23 23
6. Insulation - stator class H H H
- rotor class H H H
7. Number of phases 133
8. Number of leads 466
Electrical power circuit
1. Rated continuous active power COP kW 5.5 4.8 4.8
2. Rated power factor (lagging) 1 0.8 0.8
3. Rated continuous apparent power 1 ph COP kVA 5.5 4 4
4. Rated voltage 1ph line to line V 110 230 230
5. Rated current 1ph A 50 16 16
6. Frequency droop % < 5 < 5 < 5
7. Rated continuous apparent power 3 ph COP kVA - 6 6
8. Rated voltage 3ph line to line V - 230 400
9. Rated current 3ph A - 15 8.7
Circuit breaker
1. Number of poles 234
2. Rated current In 1ph A 50
In 1ph/3ph A 16/16 16/10
3. Thermal release It 1ph A 50
It 1ph/3ph A 16/16 16/10
4. Magnetic release Im A 3..5 In 3..5 In 3..5 In
Fault current protection
Insulation resistance kOhm 10-80 10-80
Residual current release Idn A 0.03
