Unit
1)
Air required for engine and compressor element cooling, for combustion and
for compression.
Electric refuel pump
*)
Fuel temperature max 40°C (104°F)
Remote control
Compressor dimensions
Designation All units
Capacity of compressor oil
system
l80
US gal 21.1
Net capacity of air receiver l 164
US gal 43.3
Capacity of fuel tanks
wagon / tandem
l 796 / 850
US gal 210.3 / 225
Air volume at inlet grating
(approx.)
1)
m
3
/s 13.1
cfm 2.7 10
4
Designation All units
Flow rate
*)
l/m 50
US gal/m 13
Self priming
*)
from dry up to m 2.4
ft 7.8
Designation All units
*)
Range m 350
ft 1150
*)
The maximum range in the open field is 350 metres with full
batteries. Obstacles between receiver and control unit should be
avoided.
When using several remote controlled units, please take care that
there is a distance between two receivers of at least 80 cm.
Designation Wagon Tandem
Length mm 6045 5640
inch 238.0 222.1
Width mm 2150 2140
inch 84.7 84.3
Height mm 2479 2474
inch 97.6 97.4
Weight (ready-to-operate) see indication on data plate
