Tag Desc. 1 Desc. 2 Location Sheet/
Col.
B1 Namur sensor Bypass Optional 07/6
B2 Namur sensor Closed Optional 07/6
B3 Combo sensor Optional 07/4
G1 Battery Machine 03/1
G2 Battery Machine 03/1
G3 Alternator Engine 03/3
H1 Horn Machine 05/2
H2 Lamp Flasher light Machine 05/2
K0 Relay Starter motor Engine 03/2
K1 Relay Auxilary starter 05/1
K10 Relay Remote control Option box 06/7
K3 Relay Refuel pump Optional 06/2
K4 Relay Etherstart Optional 06/6
K5 Relay Refinary equipment Optional 06/4
K8 Relay Heater Optional 07/3
LS1 Level switch Coolant level warning Machine 05/6
LS2 Level switch Coolant level shutdown Machine 05/7
LT1 Level sensor Fuel level Machine 05/5
M1 Motor Engine 03/2
M2 Pump Refueling Optional 06/1
M4 Pump Preheater Optional 07/3
M5 Stepper motor Oiltronix Optional 07/7
N1 Connector ECU Machine 03/3
Tag Desc. 1 Desc. 2 Location Sheet/
Col.
PS1 Pressure switch Air filter 05/3
PT1 Pressure sensor Vessel pressure Machine 05/2
PT2 Pressure sensor Regulating pressure Machine 05/3
PT3 Pressure sensor Oil Stop valve pressure Machine 05/4
PT4 Pressure sensor Interstage pressure Machine 05/5
PT5 Pressure sensor Air discharge pressure Optional 06/5
Q1 Circuit breaker 15A Main Machine 03/8
Q13 Circuit breaker 60A Alternator Machine 03/2
Q2 Circuit breaker 10A Engine Machine 03/3
Q3 Circuit breaker 10A Engine Machine 03/4
Q4 Circuit breaker 10A Engine Machine 03/4
Q5 Circuit breaker 10A Engine Machine 03/4
Q6 Circuit breaker 10A Refuel pump Machine 06/1
Q9 Circuit breaker 10A Preheater Optional 07/1
R1 Resistor 120 Ohm Can J1939 Machine 03/6
R2 Resistor Preheater Optional 07/2
S1 Switch Battery Machine 03/1
S2 Switch Emergency Machine 03/9
TT1 Temperature sensor LP Element temperature Machine 05/5
TT2 Temperature sensor HP Element temperature Machine 05/6
TT3 Temperature sensor Ambient temperature Machine 05/7
TT4 Temperature sensor Aftercooler air discharge
temperature
Optional 07/5
TT5 Temperature sensor Air discharge temperature Optional 06/6
