- 29 -
MARKINGS AND INFORMATION LABELS
Dangerous outlet gases.
Danger, hot surface.
Electrocution hazard.
Atlas Copco synthetic compressor oil.
Atlas Copco mineral engine oil.
Manual.
Read the instruction manual before
working on the battery.
Reset fuse.
On / off button.
Prohibition to open air valves without
connected hoses.
Rotation direction.
Inlet.
Outlet.
Compressor oil drain.
Read the instruction manual before
starting.
Service every 24 hours.
Warning! Part under pressure.
Do not stand on outlet valves.
Start-Stop indication of switch.
Do not run the compressor with open
doors.
Lifting permitted.
Use diesel fuel only.
4 bar
(58 psi)
Tyre pressure.
6 bar
(87 psi)
Tyre pressure.
Sound power level in accordance
with Directive 2000/14/EC
(expressed in dB (A)).
Fork lifting permitted.
Don’t lift here.
Read the instruction manual before
lifting.
Filler cap coolant.
Read the instruction manual before
topping up with coolant.
Service point.
Circuit breaker.
Do not run the compressor when the
baffles are not in the right position.
ABS braking system, emergency relay
valve. See section ABS braking
system.
