Atlas Copco XAHS 950 CD7 T3 APP User Manual

- 23 -
9822 0963 49
Tag Desc. 1 Desc. 2 Location Sheet/
Col.
X1 Connector XC4003/3003 Primary Machine 05/1
X10 Connector Cosmos Machine 05/8
X10A Connector Air shut-off valve Optional 06/3
X10B Connector Preheater Optional 07/3
X11 Connector Remote control 06/6
X12 Connector Coolant heater Optional 07/4
X13 Connector Timer Optional 07/1
X2 Connector XC4003 Secondary Optional 07/7
X3 Connector XC3003/4003 Remote 06/8
X5 Connector Engine diagnostic Machine 03/6
Y1 Solenoid Loading valve Machine 05/3
Y2 Solenoid Blow down valve Machine 05/4
Y3 Solenoid Air shut-off valve Optional 06/3
Y4 Solenoid Etherstart Optional 06/5
Wire size Colour code
a = 1 mm
2
0 = black
b = 1.5 mm
2
1 = brown
bx = 1.5 mm
2
NSGAFOÜ 2 = red
c = 2.5 mm
2
3 = orange
cx = 2.5 mm
2
NSGAFOÜ 4 = yellow
d = 4 mm
2
5 = green
e = 6 mm
2
6 = blue
f = 10 mm
2
7 = purple
fx = 10 mm
2
NSGAFOÜ 8 = grey
h = 25 mm
2
9 = white
l = 95 mm
2
54 = green/yellow
mx = 120 mm
2
EPR-CSP to BS6195 4C
nx = 150 mm
2
EPR-CSP to BS6195 4C
