- 23 -
Reference Name
E Glowplugs engine
F1 Circuit breaker
G1 Battery
G2 Charging alternator
H1 Lamp engine alarm
H2 Lamp compressor temperature
alarm
K0 Starter solenoid
K2 Relay starter protection
K3 Relay glowplugs
K5 Relay engine alarm
K6 Relay temperature oil compressor
K7 Relay engine oil pressure
M1 Starter motor
P1 Hourmeter
P2 Electric fuel feed pump
S1 Start switch
1 Off
2 On
3 Override - Preheat
4 Start
Reference Name
S3 Pressure switch engine oil
S4 Temperature switch engine coolant
S5 Temperature switch compressor
V1 Free wheeling diode
V2 Diode
V3 Diode
X1 Connector
X3 Auxiliary connector
Wire size Colour code
aa = 0.5 mm
2
1 = brown
a = 1 mm
2
2 = red
b = 1.5 mm
2
3 = orange
c = 2.5 mm
2
4 = yellow
d = 4 mm
2
5 = green
e = 6 mm
2
6 = blue
f = 10 mm
2
7 = purple
g = 16 mm
2
8 =grey
h = 25 mm
2
9 = white
i = 35 mm
2
10 = black
j = 50 mm
2
