- 58 -
Reversing lever, moving parts and pivot pins
Check reversing lever for ease of motion.
If fitted, apply general purpose grease via the grease
nipple until fresh grease can be seen emerging from
the bush.
If grease nipples are not fitted, then apply oil to the
reversing lever bush.
All moving parts of drawbar, handbrake lever, spring
actuator, reversing lever, linkages etc. are to be oiled
or greased as required.
Sliding locations on the height-adjusting
device
Oil threaded parts and grease toothed parts.
Initially, after 2,000 - 3,000 kilometres,
then every 5,000 kilometres.
For the first time, after 2,000 - 3,000
kilometres, then every 5,000 kilometres.
