Atlas Copco XAS 127 Kd

- 72 -
Unit
1)
Air required for engine and compressor cooling, for combustion and for
compression.
Unit dimensions
Designation
XAS 127 Kd - XAS 275 KD7
XA(S) 137 Kd - XA(S) 300 KD7
XA(S) 137 KdG - XA(S) 300 KD7G
XAHS 107 Kd - XAHS 225 KD7
Capacity of compressor oil
system
l13
US gal 3.43
Net capacity of air receiver l 35
US gal 9.25
Capacity of fuel tank l 130
US gal 34.3
Air volume at inlet grating
(approx.)
1)
m
3
/s 2.5
cfm 88
with brakes towbar
fixed adjustable
Length mm 3768 4278
in 148.3 168.4
Width mm 1676 1676
in 66 66
Height mm 1479 1479
in 58.2 58.2
Weight (ready-to-operate) see dataplate
