Instruction Manual
2954 2510 03 105
Tolerance: +/- 5% 25 l/s (6.6 US gal, 5.5 Imp gal, 0.88 cu.ft)
<FAD< 250 l/s (66 US gal, 55 Imp gal, 8.75 cu.ft)
+/- 4% 250 l/s (66 US gal, 55 Imp gal, 8.75 cu.ft)<FAD
The international standard ISO 1217 corresponds to following national standards:
British BSI 1571 part 1, German DIN 1945 Part 1, Swedish SS-ISO 1217, American ANSI PTC9
8.2.4 Design data
Compressor element
Engine
1)
Typical average load factor.
2)
With filter change.
Designation
Number of compression stages 2
Designation XRHS 506 - XRHS 1100 CD6,
XRVS 476 - XRVS 1000 CD6
Make Caterpillar
Type C13 Tier 3
Coolant Liquid
Number of cylinders 6
Bore mm 130
in 5.1
Stroke mm 157
in 6.2
Swept volume l 12.5
US gal 3.4
Imp gal 2.7
cu.in 764
Output according to DIN 6271
at normal shaft speed
kW 317.8
hp 426.2
- Load factor
1)
%70
Capacity of oil sump:
- Initial fill l 44
US gal 11.6
Imp gal 9.7
cu.ft 1.6
- Refill (max.)
2)
l42
US gal 11.1
Imp gal 9.2
cu.ft 1.5
Capacity of cooling system l 60
US gal 15.9
Imp gal 13.2
cu.ft 2.1
