Minimum
setting
Factory
setting
Maximum
setting
Delay at signal, motor overload for
compressors with YD starter
sec 0 1 1
Delay at signal, motor overload for
compressors with DOL starter
sec 0 0 0
Delay at start, starter feed-back contact
(shut-down)
sec 0 18 33
Delay at signal, starter feed-back contact
(shut-down)
sec 0 2 3
Delay at start, compressor electronic
condensate drain (warning)
sec 0 15 60
Delay at signal, compresor electronic
condensate drain (warning)
sec 5 5 5
Delay at start, dryer electronic condensate
drain (warning)
sec 0 15 60
Delay at signal, dryer electronic
condensate drain (warning)
sec 5 5 5
Service warning level for DP of air filter mbar 50 44 44
Service warning level for DP of air filter psi 0.73 0.6 0.6
Delay at signal, DP of air filter sec 0 60 255
Service plans
Minimum
setting
Factory
setting
Maximum
setting
Service plan A (operating hours) hr See remark 4000 See remark
Service plan B (operating hours) hr See remark 8000 See remark
Service plan C (operating hours) hr See remark 16000 See remark
Service plan D (operating hours) hr See remark 40000 See remark
Service plan I (operating hours) hr See remark 2000 See remark
Remark
A number of service operations are grouped (Level A, Level B, ...). Each level stands for a number of
service operations to be carried out at the programmed intervals. Consult your Atlas Copco Service Centre.
Terminology
Term Explanation
ARAVF Automatic restart after voltage failure. See Elektronikon regulator.
Compressor
elements 1/2
Element 1 is the low-pressure compressor element; element 2 is the high-pressure
compressor element.
The regulator does not accept illogical settings, e.g. if the warning level is programmed
at 205 ˚C/401 ˚F, the minimum limit for the shut-down level changes to 206 ˚C/402 ˚F.
The recommended difference between the warning level and shut-down level is 10
˚C/18 ˚F.
