Input icons
Icon Description
Pressure
Temperature
Digital input
Special protection
System icons
Icon Description
Compressor element (LP, HP, ...)
Dryer
Fan (icon only visible when installed on compressor unit)
Drain(s) (icon only visible when Electronically Regulated Drain (ERD) is installed on
compressor unit)
Filter(s)
Motor
Expansion module (Failure)
Cooler
Energy Recovery
Network settings/problem
Instruction book
