Reference Description
6 Motor cooling air inlet + compressor air inlet (for standard unit)
7 Left side view (for standard compressor)
8 Center of gravity
9 Cooling water in
10 Cooling water out
11 Circuit A
12 Compressed air outlet for standard dryer or low load dryer
13 Compressed air outlet for option: dryer bypass
14 Automatic drain of dryer with Low Load option G 1/2" (female)
15 Automatic drain of regeneration outlet G 1/2" (female)
16 Automatic drain of dryer inlet G 1/2" (female)
17 Automatic drain of intercooler G 1/2" (female)
18 Automatic drain of aftercooler G 1/2" (female)
19 Electrical cable for water shut-off valve diameter 25 mm (only for option water shut-off
valve)
20 Voltage supply: entrance for fixed speed compressors with supply ≤ 690 V
21 Voltage supply entrance:
• for fixed speed compressors with supply > 690 V
• VSD compressors (possibility 1)
• compressors with foot mounted motors
22 Top view
23 Left side view (for option: energy recovery)
24 Compressed air outlet DN 80 PN 16 acc. DIN 2633 (Scale 1:5)
25 Compressed air outlet 3" 150 Lbs acc. ANSI B16.5 (Scale 1:5)
26 Cooling water outlet of the energy recovery circuit
27 Circuit A
28 Cooling water outlet of the dryer circuit
29 Circuit B
30 Compressed air outlet
31 Cooling water inlet of the energy recovery circuit
32 Cooling water inlet of the dryer circuit
33 Automatic drain of extra aftercooler G 1/2" (female)
34 Circuit A: Water in/out DN 50 PN 16 acc. DIN 2633 (Scale 1:5)
35 Circuit B: Water in/out DN 32 PN 16 acc. DIN 2633 (Scale 1:5)
36 Rear side view
37 Grating only for option: separate air intake
38 Voltage supply: entrance for VSD compressors (possibility 2)
39 Circuit A: Water in/out 2" 150 Lbs acc ANSI B16.5 (Scale 1:5)
40 Circuit B: Water in/out 1 1/4" 150 Lbs acc ANSI B16.5 (Scale 1:5)
41 Opening for transportation
42 4 slotted holes to pull the compressor out of a container
43 Net mass of a standard compressor
Instruction book
2920 1815 04 189
