Temperature Reading
Oil Approx. 50 ˚C
Outlet of low pressure stage
120-220 °C for 7/7.5/8.6 bar standard compressors
120-235 °C for 7/7.5/8.6 bar High Ambient Temperature
compressors
120-235 °C for 10/10.4 bar standard compressors
120-260 °C for 10/10.4 bar High Ambient Temperature
compressors
Outlet of high pressure stage
100-220 °C for 7/7.5/8.6 bar standard compressors
100-235 °C for 7/7.5/8.6 bar High Ambient Temperature
compressors
100-235 °C for 10/10.4 bar standard compressors
100-260 °C for 10/10.4 bar High Ambient Temperature
compressors
Air outlet for compressors with
aftercooler Approx. 27 ˚C
Air outlet for Hot Air variants Outlet of high pressure stage
Temperature Reading
Oil Approx. 122 ˚F
Outlet of low pressure stage
248-428 °F for 7/7.5/8.6 bar standard compressors
248-455°F for 7/7.5/8.6 bar High Ambient Temperature
compressors
248-455 °F for 10/10.4 bar standard compressors
248-500 °F for 10/10.4 bar High Ambient Temperature
compressors
Outlet of high pressure stage
212-428 °F for 7/7.5/8.6 bar standard compressors
212-455°F for 7/7.5/8.6 bar High Ambient Temperature
compressors
212-455 °F for 10/10.4 bar standard compressors
212-500 °F for 10/10.4 bar High Ambient Temperature
compressors
Air outlet for compressors with
aftercooler Approx. 81 ˚F
Air outlet for Hot Air variants Outlet of high pressure stage
Oil quantity in the lubrication system of the compressor
Compressor type l cu.ft Imp gal US gal
ZR 110, ZR 132, ZR 145 29 1.02 6.38 7.66
ZT 110, ZT 132, ZT 145 55 1.94 12.10 14.53
ZR 160, ZR 200, ZR 250, ZR 275 60 2.12 13.20 15.85
ZT 160, ZT 200, ZT 250, ZT 275 88 3.11 19.36 23.25
Instruction book
314 2920 1815 04
