• Activate the menu by pressing key “Select” (F2).
Calling up service messages
• The display will show the name of the first component and the message whether service is needed or
not.
Dp Air Filter
No service required
.
Menu Select Reset
F1 F2 F3
• A vertical arrow appears indicating to scroll through the display to check the condition of the other
monitored components.
• After pressing key Select (F2), the actual measured value is shown as well as the related level at
which the component needs to be replaced:
Dp Air Filter -0.022 bar
-0.3 psi
Related service settings
Service Maximum -0.044 bar
-0.6 psi
Return Reset
F1 F2 F3
• The example shows that the service life of the filter has not yet expired.
• If a vertical arrow is shown on the third line, it can be used to call up the service level in hours.
• The service level of almost all components is indicated in running hours similar to the example
below.
Calling up the actual measured value and service level
• Call up the related service item. Consult the section above.
• Press the key “Select” :
Oil filter 8010 hrs
Related service settings
Service Maximum 8000 hrs
***Return ***Reset
F1 F2 F3
• The example shows that the oil filter needs to be replaced.
• Stop the compressor. Replace the filter.
• Reset the service message as described below.
Instruction book
58 2920 1815 04
