5.21 Saved data menu
Control panel
Function
To call up some data saved by the regulator. These data are:
• Last shut-down data
• Last emergency stop data
Procedure
Starting from the Main screen (see Main screen menu):
• Press the key “Menu” (F1).
• Press the arrow down key (1) until “Saved Data” is followed by a horizontal arrow.
• Activate the menu by pressing the tabulator key (2).
• The first option is shown “Last shutdown 1”.
• Press the tabulator key (2) to find out the date, time and other data reflecting the status of the
compressor at the last shut-down.
• If desired, scroll through the other items.
5.22 Programmable settings
Parameters
Minimum
setting
Factory
setting
Maximum
setting
Load delay time (star-delta) sec 3 10 30
Load delay time (no star-delta) sec 13 20 30
Minimum stop time sec 20 20 99
Programmed stop time sec 0 3 20
Power recovery time (ARAVF) sec 15 15 3600
Restart delay sec 0 3 255
Instruction book
2920 1815 04 103
