PennEngineering www.pemnet.com 13
Instruction Manual - RIV938
KIT FOR BLIND THREADED INSERT 1/4-20
REF. PART NUMBER QTY DESCRIPTION
1 3756100 1 KIT FOR BLIND THREADED INSERT 1/4-20 SOCKET HEAD CAP SCREW
KIT COMPOSITION
REF. PART NUMBER QTY DESCRIPTION
2 3756200 1 HEAD WITH RING NUT FOR 1/4-20 SCREW
3 3754600 1 ADAPTER FOR 1/4-20 SCREW (HOLE Ø 6.5)
4 IN-05336 (100/box) 1 SOCKET CAP SCREW 1/4-20 X 2.25”
4 IN-08057 (100/box) 1 SOCKET CAP SCREW 1/4-28 X 2.25”
5 3754700 1 HEXAGONAL JOINT FOR 1/4-20 SCREW
1
2
3
4 5
