PennEngineering • www.pemnet.com 35
Instruction Manual - RIV938
MOTOR UNIT SPARE PARTS (KIT 20)
Part number 3761000.
REF. PART NUMBER QTY DESCRIPTION REF. PART NUMBER QTY DESCRIPTION
1 3763400 1 PLANET WHEEL HOLDER 8 3327300 1 BEARING
2 3763300 1 BEARING 9 3327400 1 REAR PLATE
3 3763200 1 PLANET WHEEL 10 3327000 1 STATOR
4 3327500 1 BEARING 11 3326900 1 FRONT PLATE
5 3523400 1 ROTOR 12 3763700 1 SPACER
6 3327100 1 FIN 13 3763600 1 CROWN WHEEL
7 3327200 1 ROLLER 14 3763500 1 SNAP RING
ORDERING SPARE PARTS
Only local authorized dealers are allowed to repair the tool. Otherwise, contact the ATLAS
®
Technical Assistance
Department of PennEngineering, where qualified engineers can help to solve any problems.
COMPLETE MOTOR KIT CONSISTING OF 5 ITEMS
Part number 4316600.
NOTE: When placing an order, always reference the part number and the description.
