Instruction Manual - RIV938
KIT FOR BLIND THREADED STUD #8-32
REF
.
P
ART NUMBER
QTY
DESCRIPTION
1
4361900
1
KIT FOR BLIND THREADED STUD #8-32
1
KIT COMPOSITION
REF
.
P
ART NUMBER
QTY
DESCRIPTION
2
2561200
1
HEAD WITH RING NUT FOR #8-32 STUD (HOLE Ø 4.25)
3
4377000
1
TIE ROD FOR #8-32 STUD
4
3441800
1
HEXAGONAL JOINT
2
3
4
22
24
