VIII. PARTS LIST
Item Part No. Description QTY. Note
1 630001A
Platform
1
2 206019 Snap ring 19 24
3 630003 Pin for Drive-thru Ramp 19*452 2
4 630106 Bracket Pin 19*410 2
5 630107
Bracket
2
6 630108
Ramp
2
7 630109 Connecting pin for cylinder 25*92 2
8 630006
Cylinder
2
9 630007 Cylinder cover connecting pin 25*132 2
10 206032 Snap ring 25 10
11 630008 Lifting arms connecting pin 19*356 4
12 630009 Drive-in living arms 2
13 630010 Lifting arms connecting pin 19*405 4
14 630011 Supporting Lifting arms 2
15 630100 Socket Bolt M10*40 1
16 630013 Safety Lock 1
17 630014 Safety Bar 1
18 630105 Pin For Safety Bar 25*142 1
19 630012
Baseframe
1
20 640024 Roller Assy. 2
21 630102 Rubber Pad 438*1350*5 2
22 620034 Rubber Pad100*165*38 4
23 610070 Rubber Pad100*120*70 4
24 420020 Hex Bolt M10*115 2
25 630015 Compressed spring 15*12*55 2
26 209022 Washer 10 2
27 209056 Nylok Nut M10 3
28 209002 Power Unit 1
29 209003 Hex Bolt M8*25 4
30 209005 Nylok Nut M8 4
31 640021 Stand 1
32 206006 Washer 12 2
33 420046 Split Pin 3*20 2
34 630101 1/4*2650 Cylinder 1
35 630103 Transition Straight Fitting 1
36 209062 T-fitting 1
37 630104 1/4*550 Cylinder 1
38 209064 Cylinder Straight Fitting 1
39 420097
90q Fitting
1
40 440011 Needle valve 1
41 440009 Power Unit Straight Fitting 1
