17
Item Part No. Description QTY.
Note
 
Cover of Capacitor

  &DSDFLWRU 
  5XEEHU3DG 
 
Hex Bolt

 
Cover of Motor Terminal Box

  6ZLWFKEXWWRQ 
  5HWXUQ2SHQLQJ 
 
Oil Outlet

 
Release Valve

 
Release Valve Handle

  :DVKHU 
 
Hex Nut

 
Check Valve

 
Gear Pump

 
Oil Return Pipe

 
Filler Cap

PEAK Single Phase Hydraulic Power Unit
Item Part No. Description QTY.
Note
28A-1 209082A Motor 1
28A-2 209109
retaining wire sets
1
28A-3 209112 A.C.Connector 1
28A-4 209083A Connecting Pin for Motor 1
28A-5 209084A
Valve Body
1
28A-6 209085A Relief Valve 1
28A-7 209113 Throttle Valve 1
28A-8 209086A Washer 4
28A-9 209087A Socket Bolt 4
28A-10 209088A Inlet Pipe 1
28A-11 209089A O-ring 1
28A-12 209090A Filter 1
28A-13 209091A Hex Bolt 4
28A-14 209092A Reservior 1
28A-15 209093A Cup Head Bolt and washer 4
28A-16 209094A
Cover of Capacitor
2
28A-17 209095A Start Capacitor 1
28A-17A 209095B running Capacitor 1
28A-18 209096A Rubber pad 2
28A-19 209097A Cup Head Bolt and washer 2
28A-20 209098A
Cover of Motor Terminal Box
1
28A-21 209099A
Switch Button
1
28A-22 209110A Oil Return Pipe 1
