Service manual SUNTEST XLS/ XLS+ Page 14
„6“: V24- Test
Interface- Test is not active.
„7“: Display- Test
After start you the different segments of the display are checked automatically.
„8“: Keyboard- Test
The display is black. By pressing the different keys you can check the keyboard.
„9“: NV- RAM- Test
The RAM is checked automatically. A counter runs from 1000....1255 bit.
„0“: NV- RAM- Fill
Caution! All saved data will be erased!
This function resets the whole memory to default values.
(all customer´s programs will be erased, clock 0.00, operating hours 0............)
„arrow up“: filter factors
The display shows the saved internal filter factors.
„arrow down“: Edit- function
With this function you can edit and change the serial number, operating hours machine, operating
hours lamp in the controller.
„Enter“: type of machine
With the arrow- keys you can enter or change either CPS+ or XLS+ in the controller.
With „
Escape
“ you can always jump out of a specific function.
With „
Stop
“ you can stop the service software at any time.
