Atlona AT-UHD-EX-70-2PS Series User Manual

7
Video Resolutions
Video 480i, 480p, 576i, 576p, 720p@50/59.94/60Hz, 1080i@50/59.94/60Hz,
1080p@23.98/24/25/29.97/30/50/59.94/60Hz, 2048x1080p
3840x2160@24/25/30/50/60Hz (UHD), 4096x2160@24/25/30/50/60Hz
VESA 640x480, 800x600, 1024x768, 1152x864, 1280x768, 1280x800,
1280x1024, 1360x768, 1366x768, 1400x1050, 1440x900, 1600x900,
1600x1200, 1680x1050, 1920x1200, 2048x1536, 2560x1600,
2560x2048
Colorspace YCbCr, RGB
Chroma Subsampling 4:4:4, 4:2:2, 4:2:0 (UHD only)
Color depth 8-bit, 10-bit, 12-bit
Audio
Formats PCM 2Ch, LPCM 5.1, LPCM 7.1, Dolby Digital, DTS 5.1,
Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio
Sample Rate 32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
Bit rate up to 24-bit
Distance
HDMI 4K up to 5 meters up to 15 feet
HDMI IN/OUT up to 10 meters up to 30 feet
CAT5e/6 @ 4K up to 35 meters up to 115 feet
CAT6a/7 @ 4K up to 40 meters up to 130 feet
CAT5e/6 @ 1080p up to 60 meters up to 197 feet
CAT6a/7 @ 1080p up to 70 meters up to 230 feet
Signal
Bandwidth 10.2 Gbps
CEC Yes
HDCP Compliant
Temperature
Operating 0°C to 50°C 32°F to 122°F
Storage -20°C to 60°C -4°F to 140°F
Humidity 20 to 90% non-condensing
Power
Consumption 1.55W
Idle Consumption 0.58W
Supply Input: AC100~240V 50/60Hz
Output: DC 5V 1.2A
Dimension
H x W x D 25 x 109 x 76 (mm) 0.98 x 4.29 x 2.99 (inch)
w/ears 27 x 129 x 76 (mm) 1.06 x 5.08 x 2.99 (inch)
Weight
Device 0.25 kg 0.55 lbs
Shipping 0.8 kg 1.76 lbs
Certification
Power Supply CE, FCC, cULus, C-Tick, RoHS, CCC
atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
Specifications
