Atmel SAM C21 Xplained Pro User Manual

Designator From To Comment
J502 VS_LIN VCC_TARGET_P3V3_P
5V0
Mount this jumper
(JS500) to power the
LIN transceiver from
VCC_TARGET_P3V3_P
5V0. Remove this
jumper when the LIN
transceiver is powered
from the LIN bus.
Default setting in
production is mounted.
J504 CAN device, Standby
pin
GND Cut this jumper to
explore the standby
functionality of the CAN
transceiver (ATA6561).
The footprint is 0603
sized.
