Hoses
Your regulator was function tested and is ready for use from the factory. You will need
to install your high pressure gauge, instruments and low pressure accessories such as
inflators. If you are in doubt on how to do this, see your Atomic Aquatics professional
retailer for assistance.
Low Pressure Hoses (LP thread size 3/8"-24)
Your regulator has either 5 low-pressure (LP) ports on the swivel end of the
first stage (T3, T2x, ST1, M1, B2) or 7 low pressure ports (Z2/Z3) in a fixed orientation.
Choose the ports that give you the best orientation for your particular set-up. The LP
port plugs can be removed by unscrewing with a 5/32" (4mm) hex wrench. Install the
LP hoses into the port and snug up with a wrench. Do not overtighten as this will not
improve the seal and may damage the threads.
High Pressure Hoses (HP thread size 7/16"-20)
Your regulator has 2 high pressure ports (marked HP) on either side of the body. The HP
ports and plugs are larger in size than the LP plugs. Remove the plugs with the same
hex wrench and install the high pressure gauge hose into the high pressure port and
snug it with a wrench.
System Set-Up
