Atomic Reactor 112 - Floorboard Style Modelers

10
Floorboard Style Modelers
RETURN
SEND - L
EFFECTS
LOOP
SEND - R
MODEL REACTOR 11
2
Atomic Amplifiers LLC.
Orange CT.
FUSE
0101010101
!CAUTION!
RETURN
SEND - L
EFFECTS
LOOP
SEND -
R
MODEL REACTOR 11
2
Atomic Amplifiers LLC.
Orange CT.
FUSE
0101010101
!CAUTION!
X
Using two Reactor
112s Install blank
templates onto the
DS-1 docking units.
(see page 10)
Y
Replace the DS-1’s back into
the docking bays located in the
top of the Reactors making
sure that the dock locks click
into position.
Z
Plug the Left and Right
outputs of your Foot
Controller style modeler or
preamp into the pair of
Reactor’s RETURN inputs.
[
If using outboard effects pedals
or devices with your modeler,
connect them as normal per the
manufacturer’s instructions.
\
It is a good idea to make
sure the output levels are
turned down on your
modeler.
]
Turn the modeler’s
power on.
^
Turn the Reactors power switches to
the ON position (they should light up).
_
Bring up the levels on your modeler and
switch to some of your favorite presets.
