ATOMRC Swordfish - Detailed Installation Steps; Install Motor, ESC, and LED; Connect Servo and ESC to Quick Release Board; Install FC and VTX System

Install the Motor,ESC and LED
将电机、电调、LED灯，安装到左右机翼上
6
5
7
Install the wing
合并左右机翼，进⾏⻜⾏前调试，
完成安装。
图传安装⽊⽚
图传仓盖
摄像头打印件
GPS舱
前置摄像头安装位
Install the FC and
VTX system if needed
根据需求安装图传
摄像头和其他外设
Connect the servo and ESC to the quick release board
参照接线图，将机翼电调、舵机的线接到快拆板上
Receiver or FC/接收机或⻜控 Wing/机翼
6
10 0
+
-
G
5V
s
Swordfish QRC
Aux
M
G
S
5V
G
Motor
Servo
Aux
MOTOR
8
