4
1.1 Terminal plug for connecting the chuck
1.2 White plug cable for Atomstack 1.3 Black plug wire other brands use
Connection socket
Y-axis motor wire plug Chuck motor plug Y-axis motor wire plug Chuck motor plug
3.Connection cable use
