4
1.1 Spina terminale per il collegamento del mandrino
1.2 Cavo spina bianco per Atomstack 1.3 Filo spina nero utilizzato da altre marche
Presa di collegamento
Spina del cavo del motore dell'asse Y Spina motore mandrino Spina del cavo del motore dell'asse Y Spina motore mandrino
3.Uso del cavo di connessione
