NO. 1 THRUST WASHER LOCATION
WITH NON-SYMETRICALLY LOCATED
HOLES FOR THRUST WASHER
NO. 3 THRUST WASHER
LOCATION WITH CAST
GROOVES FOR THRUST
WASHER RETENTION
CHAIN COVER AND THRUST WASHERS
PRIOR TO OCTOBER 13, 1995
REQUIRES THE BRONZE NO. 3
THRUST WASHER WITH TANGS ON
THE OUTSIDE DIAMETER
PART NUMBER E6DZ-7G096-A
REQUIRES THE PLASTIC NO. 1
THRUST WASHER WITH TABS THAT
ARE NON-SYMETRICALLY LOCATED
PART NUMBER E6DZ-7G099-A
NUMBER 3
THRUST WASHER
NUMBER 1
THRUST WASHER
98
Copyright © 2002 ATSG
AUTOMATIC TRANSMISSION SERVICE GROUP
Technical Service Information
Figure 85
