NO. 1 THRUST WASHER LOCATION
WITH SYMETRICALLY LOCATED
HOLES FOR THRUST WASHER
NO. 3 THRUST WASHER LOCATION
WITH SYMETRICALLY LOCATED
HOLES AND CAST GROOVES
FOR THRUST WASHER RETENTION
CHAIN COVER AND THRUST WASHERS
OCTOBER 13, 1995 AND BEYOND
CAN USE EITHER OF THE
PART NUMBERS LISTED ABOVE
(BLACK PLASTIC)
F5DZ-7G096-A
(BRONZE)
E6DZ-7G096-A
REQUIRES THE PLASTIC NO. 1
THRUST WASHER WITH TABS THAT
ARE SYMETRICALLY LOCATED
PART NUMBER F5DZ-7G099-A
NUMBER 3
THRUST WASHER
NUMBER 1
THRUST WASHER
99
Figure 86
Copyright © 2002 ATSG
AUTOMATIC TRANSMISSION SERVICE GROUP
Technical Service Information
