ATV Flail Mower Assembly
Number Part Number Name & Specifications Quantity Remark
1 GB5783-86 BlotM12x30 19
2 GB93-87 Spring Washer 12 9
3 GB97.1-85 Plain Washer 12 37
4 MFP120.00.1 Fixing Sleeve 1
5 06 Circlip 35 1
6 GB894.1-85 Circlip 62 2
7 GB893.1-86 Bearing 6007Z 2
8 GB278-89 Driving 1
9 MFP120.00.1 Belt Wheel 1
10 52 Clutch Key 6.3x7x50 1
11 MFP120.00.0 Protecting For 1
12 17 Transmission Locking Nut 42
13 GB1096-79 M12 4
14 MFP120.00.0 Blot M12x35 8
15 18 Blot M8x20 8
16 GB6184-86 Spring Washer 8 1
17 GB5783-86 Supporting Plate (R) 2
18 GB5783-86 Bearing UC205 1
19 GB93-87 Roller Weldment 1
20 MFP120.0.00.1 Gasoline Engine 1
21 55 Supporting Plate (L) 1
22 EF100.00.01 Deck Weldment 1
23 2 RK120.017 Split Pin 4x28 1
24 JF390 Adjusting Plate (R) 1
25 MFP12.000.1 Adjusting Plate (L) 1
26 EF100.00.101 Sleeve 56
27 RK120.114a Blade 28
28 GB5782-86 Blot M12x80 28
29 EF100.00.122 Baffle 12
30 EF100.00.121 Baffle 1
31 MFP120.00.10 Shaft 1
32 9 Protecting Bracket 2
33 MFP120.00.02 Tension Spring 1
34 4 Bearing Seat 90207 2
35 MFP120.00.11 Oil Seal FB55X80X8 2
36 6UC207-Z Oil Sealing Sleeve 2
37 GB13871-94 Oil Cup M8x1 1
38 RK120.109 Bracket For Tension 1
39 GB1152-89 Spring 1
40 6 Locking Nut 10 1
