28
3
0～10V(0～4V)
0～10V\0～4V analog output signal
(The output range can be configured)
4
AGND
6
CON2
OUT
1
LA-EN+
DC24V laser enable output signal
2
LA-EN-
3
GAS+
DC24V output connected to solenoid valve
to control blowing
(Drive current Max 2A)
4
GAS-
7
CON3
IN
1
LA-ALM+
Laser alarm input port
(DC24V high level valid)
2
LA-ALM-
3
LA-ON+
Connect to the hand gun button switch,
turn on the light
(Short the two points to give out light
and breathe out)
4
LA-ON-
8
CON4
IN/OUT
1
RS232-R
Reserved
2
RS232-T
OUT
3
LA-Red+
Red light indicating control signal
(DC24V high level effective)
4
LA-Red-
9
CON5
OUT
1
SW-IN1+
Reserved
2
SW-IN1-
IN
3
+15V
Controller DC±15V power input
4
GND
5
-15V
10
CON6
OUT
1
NC
Reserved
