HWS5000 Welding System Controller
User Manual
Manual For Welding System Equipment (control part)
Version: V5.0
1. Equipment installation and wiring
1.1 Wiring instructions for touch screen terminals
Touch screen wiring terminal
Terminal wiring instructions:
Power terminal: The screen uses 24V DC power supply. The terminals from right to
left are: power supply positive, power supply negative, and ground wire.
RS485 communication terminal: This terminal and the controller RS485
communication terminal are connected through the RS485 communication line.
