35
light will be emitted only once per press. The light emission time is determined by the
spotting time. If you need to spot the light again, you need to release the switch and press
the light switch again.
Scaly welding line: after the laser is enabled, the light emitting conditions are met,
the light spot swings slowly to achieve the effect of scal pattern.
The enable button has an indication function. The closed and open states are as
shown in the figure below:
Turn off enable Turn on enable
Enable and switch control buttons:
"Red light indicator" button: Turn on/off the red light indicator.
"Spot enable" button: Turn on/off the light spot swing.
"Light emitting mode" button: Set the light emitting mode of "continuous"\"spot shot".
"Laser enable" button: turn on/off the laser enable, only the laser enable
is turned on can light be emitted.
"Wire feed switch" button: Turn on/off the wire feed.
"Wire feeding mode" button: can switch between inching wire feeding and automatic
wire feeding. When the wire feeding is inching, the wire feeding switch must be pressed
continuously before the wire feeder moves, and the wire feeding switch stops when the
wire feeding switch is released. During automatic wire feeding, if the wire feeding is turned
on, the wire will be fed automatically during the light emitting process, and the wire will
stop automatically when the light is stopped.
"Wire feeding direction" button: It can be switched to wire feeding and wire return. In
the automatic wire feeding mode, the wire feeding direction is "Wire feeding" and cannot
be modified.
